Inclined Shear
Range： Inclined Shear
| Item | Unit | SHIC-800 | SHIC-1000 | SHIC-1250 | SHIC-1500 |
| Shearing force | ton | 400x2Cyl | 500x2Cyl | 625x2Cyl | 750x2Cyl |
| Shear opening height(Max) | mm | 1100 | 1100 | 1200 | 1200 |
| Cutting width | mm | 800 | 1000 | 1000 | 1200 |
| Charging box dimensions(LxW ) | mm | 9000x2400 | 10000x2500 | 10000x2650 | 10000x2800 |
| System pressure | Mpa | 31.5 | 31.5 | 31.5 | 31.5 |
| Electric motor | KW | 180(90KWx2) | 300(75KWx4) | 360(90KWx4) | 440(110KWx4) |
| Cutting times | times/min | 4(empty) | 4(empty) | 4(empty) | 4 (empty) |
| capacity | tons/hour | max 20 | max30 | max 40 | max 50 |
Economy, Semi-Portable
→ SHC/SHH two series cover heavy scrap
→ 800 to 2000tons shearing force
→ Capacity 20-60tons
→ Charging box 9000 to 11000mm
→ Materials compression: Flipper/ Side compression
Application Reality
Inclined Shear
All features of the SIMVIC product line for maximum durability, performance, efficiency and maintainability
